LN-S009-4K 12VDC Video Converter 4K HDMI To 12G-SDI Robust Design

Products

LN-S009-4K 12VDC Video Converter 4K HDMI To 12G-SDI Robust Design

MOQ:	1
Price:	$29
Standard Packaging:	Carton
Delivery Period:	7-15 working days
Payment Method:	T/T
Supply Capacity:	2500

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Lntech

Certification

CE ISO

Model Number

LN-S009-4K

Highlight:

Robust Design Video Converter

12VDC Video Converter

Robust HDMI To SDI Converter

Product Description

LN-S009-4K: 4K HDMI to 12G-SDI Converter

Model: LN-S009-4K | Input: 1x HDMI 2.0 (4K30/HDR) | Output: 1x 12G-SDI | Audio: Multi-Channel Embedding | Power: 12V DC

1.0 Product Summary

The LN-S009-4K is a high-performance converter designed for ultra-high-definition workflows. It transcodes HDMI 2.0 signals into broadcast-grade 12G-SDI, supporting 4K resolution, HDR, and multi-channel audio. It represents the pinnacle of format conversion for professional, future-proof applications.

2.0 Key Features & Benefits

UHD & HDR Capable: Full support for 4Kp30 and HDR (HDR10/HLG) pass-through.
12G-SDI Output: Native support for the highest bandwidth SDI standard for 4K transport.
Intelligent Downscaling: Automatically provides a second output resolution (e.g., 1080p) from the 4K source for simultaneous HD monitoring or recording.
Advanced Audio: Handles up to 8 channels of embedded audio for immersive formats.
Robust Design: Metal enclosure ensures stable operation under heavy processing loads.

3.0 Technical Specifications

3.1 Interface & Signal Details

Parameter	Specification
Input Port	1 x HDMI (Type A, Ver 2.0)
Input Standard	HDMI 2.0, HDCP 1.4 / 2.2
Max Input Resolution	3840x2160p30 (4K), 1080p60
HDR Support	HDR10, HLG
Output Port	1 x BNC (Female, 75Ω)
Output Signal	12G-SDI (SMPTE 2082-1), 3G-SDI, HD-SDI
Audio Support	Embeds HDMI audio into SDI; Supports up to 8 channels; 32-192 kHz
Max SDI Distance	12G: 50m, 3G: 70m, HD: 100m (Using high-quality cable)

3.2 Physical, Power & Environmental

Parameter	Specification
Power Supply	DC 12V / 2A (External Adapter Included)
Power Consumption	< 8W
Dimensions	100 x 50 x 28 mm estimated
Weight	180 g
Operating Temperature	0°C to +40°C
Operating Humidity	5% to 90% RH (non-condensing)
Case Material	Metal

4.0 Resources & Support

4.1 Documentation & Downloads

Datasheet (PDF)
User Manual (PDF)
FAQ & Troubleshooting

4.2 What's Included

LN-S009-4K HDMI to 12G-SDI Converter
Power Adapter (DC 12V/2A)
User Manual

4.3 Frequently Asked Questions

Q: Does it support 4K@60Hz?
- A: No, the LN-S009-4K supports a maximum of 4K@30Hz via HDMI input. For 4K@60Hz, a more advanced model would be required.
Q: Can I use it with my existing 3G-SDI equipment?
- A: Yes. The converter can automatically downscale the 4K input to 1080p and output it as a standard 3G-SDI signal, ensuring full backwards compatibility.
Q: Why does it require a 12V power adapter instead of 5V?
- A: Processing 4K and 12G-SDI signals requires significantly more power. The 12V/2A adapter ensures stable and reliable operation under the high computational load.

4.4 Target Applications

Linking 4K HDMI cameras (cinema, high-end PTZ) to 12G-SDI live switchers.
Integrating 4K media players and computers into UHD broadcast or presentation systems.
Future-proofing video infrastructure for 4K HDR production.
Medical imaging and simulation requiring 4K resolution.
High-resolution digital signage control centers.

LN-S009-4K 12VDC Video Converter 4K HDMI To 12G-SDI Robust Design 0
