LN-802ST 2MP Starlight CCTV Camera With Motion Detection Privacy Masking
  • name
  • name
  • name
  • name
  • name
  • name

LN-802ST 2MP Starlight CCTV Camera With Motion Detection Privacy Masking

MOQ: 1
Standard Packaging: Carton
Delivery Period: 7-15 working days
Payment Method: T/T
Supply Capacity: 2500
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Lntech
Model Number
LN-802ST
Imaging Core:
1/1.8" Sony IMX385 STARVIS CMOS
Signal Processing:
EN771 Platform
Resolution & Speed:
2MP (1920x1080) @ 25/30fps
Sensitivity:
0.001Lux (Color); 0.0001Lux (IR ON)
Dynamic Range:
True WDR: 150dB
Lens Options:
Fixed 3.6mm Or Motorized Varifocal (2.8-8mm)
IR System:
IR Cut Filter (ICR), 40m IR Range
Key Features:
POC, Sens-Up (x32), 3D-DNR, OSD
Build:
Metal Housing, IP67
Highlight:

Privacy Masking Starlight CCTV Camera

,

Motion Detection Starlight CCTV Camera

,

Privacy Masking 2MP Starlight Camera

Product Description

Explore the LN-802ST specs: Sony IMX385 sensor, 2MP, 150dB WDR, 0.0001Lux, POC support, IP67. Download datasheets & manuals. For professional low-light security.

LN-802ST Starlight Camera

Model: LN-802ST | Platform: EN771 + IMX385 | Lens: 3.6mm or 2.8-8mm Motorized | Housing: IP67 Metal

A high-performance 2MP starlight camera with Sony IMX385 sensor and 150dB WDR. Features POC support and a rugged IP67 metal housing for demanding outdoor applications.

1.0 Key Features at a Glance
Section Key Attributes
Imaging - 1/1.8" Sony IMX385 STARVIS Sensor
- 2MP (1920x1080) @ 25/30fps
- 0.001Lux (Color) / 0.0001Lux (IR)
- 150dB True Wide Dynamic Range
Lens & IR - Standard 3.6mm Fixed Lens
- Optional 2.8-8mm Motorized Zoom
- 40m IR Distance, Auto ICR
Functionality - Power over Coax (POC) Support
- Sens-Up (x32), 3D-DNR
- Motion Detection, Privacy Masking
- Multi-language OSD Menu
Build & Design - Full Metal Housing
- IP67 Weatherproof Rating
- 150*85*70mm
2.0 Detailed Product Information
2.1 Description

The LN-802ST is a professional-grade camera engineered for ultra-low-light surveillance environments. Leveraging the superior light sensitivity of the Sony IMX385 sensor and advanced 150dB WDR processing, it delivers clear and detailed images in scenes with extreme contrast or minimal lighting. Its robust IP67-rated metal build and optional features like POC and motorized zoom make it a versatile and reliable choice for critical security installations.

2.2 Low-Light & WDR Performance

  • Starlight Sensitivity: The camera achieves exceptional low-light performance, providing usable color video at 0.001 Lux and switching to high-sensitivity B/W mode with IR illumination for 0.0001 Lux performance.

  • 150dB WDR: Effectively compensates for backlight and shadows, ensuring details are visible in both the brightest and darkest parts of the image.

2.3 Configuration Options

  • Lens: Available with a fixed 3.6mm lens for a standard view or an optional 2.8-8mm motorized varifocal lens for adjustable field of view, controllable remotely via the OSD.

  • Power over Coax (POC): The optional POC function allows for simpler installation using a single cable for both power and video transmission.

2.4 Physical Build

  • Housing: Built with a metal casing for maximum durability, EMI shielding, and effective heat dissipation.

  • Weatherproofing: The IP67 certification ensures complete protection against dust and water ingress, making it suitable for outdoor use in all weather conditions.

3.0 Comprehensive Specification Table
Group Parameter Specification
General Model Code LN-802ST
  Image Sensor 1/1.8" Sony IMX385 CMOS
  Processor EN771
Video Resolution 2MP (1920x1080)
  Frame Rate 25/30fps
Lens Standard 3.6mm (Fixed)
  Optional 2.8-8mm (Motorized Zoom)
Low Light Color 0.001 Lux
  B/W (IR on) 0.0001 Lux
  Day/Night Auto ICR
  IR Distance 40 meters
  Sens-up x2, x4, x8, x16, x32
Image WDR 150dB
  DNR 3D-DNR
  Features AGC, HLC, BLC, Privacy Mask, Motion Detect
Power Input DC 12V
  POC Supported (Optional)
Mechanical Material Metal
  Protection IP67
  Dimensions 150 x 85 x 70 mm
  Weight 550g
Control OSD Multi-language

Contact us for OEM pricing and technical support. Specify your lens and POC requirements when ordering.
