2592x1944 5MP Starlight Camera Module High Resolution Surveillance Camera

Explore the 5MP starlight module specs: Sony sensor, 2592x1944 resolution, 0Lux IR, switchable AHD/TVI/CVI/CVBS/EX-SDI outputs. Download datasheets & manuals. Designed for easy integration.

Model: 5MP Starlight | Sensor: 1/2.8” Sony CMOS | Resolution: 2592x1944 | Lens: 2.8-12mm Manual Zoom

A high-resolution 5MP camera module with starlight low-light performance and integrated IR. Features selectable 6-in-1 video output (AHD, TVI, CVI, CVBS, EX-SDI) for universal DVR compatibility.

2.1 Description
This board-level camera module is designed for high-definition surveillance applications requiring superior detail. Utilizing a Sony CMOS sensor, it captures 5-megapixel video at 25/30 frames per second. Its selectable video output ensures compatibility with all popular recording systems, from modern HD analog to digital EX-SDI. Key features like 120dB WDR, DEFOG, and powerful IR illumination make it suitable for challenging environments.

2.2 Output Options
The module provides support for multiple video formats on a single board:

• Analog HD: AHD, TVI, CVI

• Standard Definition: CVBS

• Digital: EX-SDI
  The output format is selected via an external dip-switch or OSD menu, providing ultimate flexibility.

2.3 Image Performance

• Superior Detail: 5MP resolution provides exceptional clarity for identifying critical details.

• Starlight Low-Light: Advanced sensor technology delivers color images in near darkness (0.01Lux).

• Total Darkness Vision: 24 integrated SMD IR LEDs provide illumination for clear B/W video at 0 Lux.

• Enhanced Visibility: 120dB WDR handles backlight, while DEFOG clears atmospheric obscurants.

2.4 Lens & Focus

• Lens: Includes a high-quality 5MP 2.8-12mm manual varifocal lens with an M12 mount.

• Adjustment: The manual zoom and focus rings allow precise adjustment of the field of view during installation.

2.5 Physical Installation & Control

• Configuration: All camera settings (WDR, DNR, Privacy Mask, etc.) are managed through an On-Screen Display (OSD) menu controlled via the coaxial cable from a compatible DVR.

• Power: Standard 12V DC input.

Contact us for OEM pricing and technical support.
