LN-331 2MP AHD Camera SDI Security SDI Camera IP67 Weatherproof
  • name
  • name
  • name
  • name
  • name
  • name

LN-331 2MP AHD Camera SDI Security SDI Camera IP67 Weatherproof

MOQ: 1
Standard Packaging: Carton
Delivery Period: 7-15 working days
Payment Method: T/T
Supply Capacity: 2500
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Lntech
Model Number
LN-331
Imaging Core:
1/3" Panasonic CMOS Sensor
Signal Processing:
EN771T + MN34227 Platform
Resolution & Speed:
2MP (1080p) @ 30fps
Lens:
Fixed 3.7mm
Power Interface:
DC 12V / POC (Optional)
Key Features:
WDR, 3D-DNR, Digital Zoom, HLC, BLC
Control Interface:
Coaxial OSD
Mechanical:
Metal Housing, IP67, 39x39x31mm
Highlight:

2MP Mini Camera IP67

,

Weatherproof 2MP Mini Camera

,

Weatherproof SDI Security Camera

Product Description

Explore the LN-331 specs: Panasonic sensor, 2MP, AHD 1080P, POC support, IP67 metal housing. Features WDR, 3D-DNR. Download datasheets. Designed for easy integration.

LN-331 2MP Mini Camera Module

Model: LN-331 | Platform: EN771T + MN34227 | Sensor: 1/3" Panasonic CMOS | Size: 39x39x31mm

A compact 2MP camera module with Panasonic sensor and 1080P resolution. Features POC support and a rugged IP67 metal housing for demanding applications.

1.0 Key Features at a Glance
Section Key Attributes
Imaging - 1/3” Panasonic CMOS Sensor
- 2MP (1080P) @ 30fps
- Fixed 3.7mm Lens
Power & Setup - DC 12V Standard Input
- POC (Power over Coax) Support
- Coaxial OSD Control
Functionality - WDR, 3D-DNR, Digital Zoom
- HLC, BLC
- Motion Detection, Privacy Masking
Build & Design - Full Metal Housing
- IP67 Weatherproof Rating
- Ultra-Compact: 39x39x31mm
2.0 Detailed Product Information

2.1 Description
The LN-331 is a high-definition mini camera module designed for discrete surveillance and OEM integration where space is limited. It utilizes a Panasonic CMOS sensor and the EN771T + MN34227 processor to deliver 1080p resolution. Its support for Power over Coax (POC) and sealed IP67-rated metal housing make it a versatile and reliable choice for a variety of security and industrial applications.

2.2 POC Functionality
The optional POC function is a key feature for integration. It allows the camera to receive power directly from the DVR over the same coaxial cable used for the video signal, reducing cable requirements and installation time.

2.3 Image Performance

  • High Definition: Provides 2MP resolution for detailed imaging.

  • Adaptive Lighting: WDR handles high-contrast scenes. 3D-DNR ensures a clean image in low light, and HLC/BLC manage specific over-exposure issues.

  • Control: All image settings are easily configured via the built-in On-Screen Display (OSD) menu.

2.4 Physical Build

  • Housing: Constructed from metal for superior durability and heat dissipation.

  • Weatherproofing: The IP67 rating guarantees protection against dust and water immersion.

  • Dimensions: The ultra-compact form factor (39x39x31mm) allows for installation in extremely tight spaces.

3.0 Comprehensive Specification Table
Group Parameter Specification
General Model Code LN-331

Image Sensor 1/3” Panasonic CMOS

Processor EN771T + MN34227
Video Resolution 1080P@30fps, 720P@30fps

Lens 3.7mm Fixed
Image Features WDR Yes

DNR 3D-DNR

Zoom Digital Zoom

HLC Yes

BLC Yes

Privacy Mask Yes

Motion Detect Yes
Power Input DC 12V

POC Supported (Optional)
Mechanical Material Metal

Protection IP67

Dimensions 39 x 39 x 31 mm

Weight 50g

Contact us for OEM pricing and technical support. Specify if POC functionality is required when ordering.
